TAWIL ISO2531 ductile iron pipes class k9

FOB Reference Price:Get Latest Price
$600.00 - $900.00 / Inches | 1 Inch/Inches ISO2531 ductile iron pipes class k9 sample available (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shanxi, China
Brand Name:
TAWIL ductile iron pipes class k9
Model Number:
push in, Push in with restrained groove, mechanical joint, flange ty
Length:
5.7M ,6M or as your needed
Standard:
ISO2531/BSEN545/ EN598
Application:
Potable/sewage water pipeline
Shape:
Round
Hardness:
less than 230HB
Pipe Wall Thickness:
CLASS K7,K8,K9,K10,K12; CLASS C
Pull Strength:
more than 420MPa
Yield (≥ MPa):
300
Material:
Ductile Iron
Type:
casting
Coating:
Metallic zinc coating + Bitumen complying with ISO8179 EN545, EN598
Lining:
Portland or High alumina Cement mortar lining complying with ISO4179
Joint structure:
push in, mechanical joint, flange-Type
Transportation:
Bulk vessel or container
Elongation:
more than 10
Bending strength:
more than 590
Zinc spraying:
a. 130g/m2 b. 210g/m2
Bitumen coating:
more than 70μm
Hydraulic pressure test:
100%
Flange pipe:
weld on flange or screw on flange pipe in any length
Diameter:
DN80-DN1400MM
Supply Ability
Supply Ability:
10000 Ton/Tons per Month socket spigot end pipe as customer's demand
Packaging & Delivery
Packaging Details
ISO2531 ductile iron pipes class k9 packed in bundle with steel belt or container
Port
XINGANG,CHINA
Lead Time :
Shipped in 3 days after payment

TAWIL ISO2531 ductile iron pipes class k9 TAWIL ISO2531 ductile iron pipes class k9 TAWIL ISO2531 ductile iron pipes class k9 TAWIL ISO2531 ductile iron pipes class k9 TAWIL ISO2531 ductile iron pipes class k9

 ISO2531 DUCTILE IRON PIPE
Product Description



TAWIL ISO2531 ductile iron pipes class k9 product data:

        Joint structure >>>

       Mechanical Properties >>>



Standard

Product

Nominal Diameter DN mm

Tensile strength N/mm2

Yield  strength    N/mm2

Elongation  %

Hardness  HB

ISO2531 EN545:2010 EN598:2009

Ductile iron pipes

DN100~1000mm

420

300

10

230

DN1100~2600mm

300

7





         Pressure gauge for hydrostatic testing standard >>>





Product

Nominal Diameter                     DN(mm)

Tensile strength                 N/mm2

Yield strength                           N/mm2

Ductile iron pipes

100~300

50

10

350~600

40

700~1000

32

1100~2000

25

2200~2600

18



         Internal & External Protections >>>



Internal Protection

 External Protection

Cement mortar lining complying with ISO4179 EN545:2010.

Metallic zinc coating(130g/m2) + Bitumen complying with ISO8179 EN545:2010.



            Note: Other internal and external protections can be done as per customer's requirements.

     Ductile iron Pipe Technique parameter >>>

      Class K9 "T-Type" Permission Deflection Angles >>>

        Class C "T-Type" Working Pressure>>>



Packaging & Shipping

       Shipment by Container

     Shipment by Bundle



Ductile iron Pipe packed in bundle with steel belts suit to sea transport.



Production process







 TYPE TESTING



Our Services

        Sample Available.

      Accessories available: RUBBER RING (SBR, EPDM)

      Hydrostatic testing: 100%  Hydrostatic test



Your Investment, Our Commitment ......





Company Information







Product image
